MANIFill Nano

MANIFill Nano Composite

MANIFill Nano Composite – with outstanding mechanical properties! Light-curing nano-composite with an ultra-fine, radiopaque glass filler for adhesive filling therapy.

Product Characteristics

  • Excellent mechanical properties: E-modulus 16575 MPa
  • Optimized flow behavior and easy handling
  • Low shrinkage 1,66%
  • Outstanding polishability
  • High radiopacity 220%

Indications

  • Anterior and posterior restorations of Classes I-V
  • Inlays, onlays, and veneers
  • Extended fissure sealing on molars and premolars
  • Core build-ups
  • Splinting of loosened teeth
  • Shape and shade corrections for improved aesthetics

Step by Step

Preparation of the cavity

© Dr. Sudhanva
  • Clean teeth with fluoride-free polishing paste.
  • Prepare the cavity according to the adhesive technique.
  • Clean cavity with water spray and dry.
  • Ensure draining, rubber dam recommended.
Apply the adhesive system
  • Etch and bond the tooth surface according to the manufacturer’s instructions.
Composite application
  • Insert the material from the syringe or coil into the cavity and model.
  • Maximum layer thickness 2 mm.
Curing
  • Expose each layer for 20 seconds using a dental polymerization unit.
  • Hold the light guide as close as possible to the surface.
Finishing and polishing
  • After polymerization, finish directly with finishing diamonds, silicone polishers or polishing brushes.
  • Check occlusion and articulation.
Special notes
  • Do not place the operating light too close to the material to avoid premature curing.
  • Carry out polymerization with a device in the 350 – 500 nm spectrum.
A1, A2, A3, A3, 5, B1, C2, OD B2, OD A2

Vickers Hardness 948 MPa
Bending strength 157 MPa
E-module 16575 MPa
Compressive strength 432 MPa
Diametral tensile strength 56 MPa
Radiopacity 220%
Vol. shrinkage 1,66%
All technical data are average values and may vary slightly in each delivery batch.
