MANIFill Nano
MANIFill Nano Composite
MANIFill Nano Composite – with outstanding mechanical properties! Light-curing nano-composite with an ultra-fine, radiopaque glass filler for adhesive filling therapy.

Product Characteristics
- Excellent mechanical properties: E-modulus 16575 MPa
- Optimized flow behavior and easy handling
- Low shrinkage 1,66%
- Outstanding polishability
- High radiopacity 220%
Indications
- Anterior and posterior restorations of Classes I-V
- Inlays, onlays, and veneers
- Extended fissure sealing on molars and premolars
- Core build-ups
- Splinting of loosened teeth
- Shape and shade corrections for improved aesthetics

Step by Step
Preparation of the cavity

© Dr. Sudhanva
- Clean teeth with fluoride-free polishing paste.
- Prepare the cavity according to the adhesive technique.
- Clean cavity with water spray and dry.
- Ensure draining, rubber dam recommended.
Apply the adhesive system
- Etch and bond the tooth surface according to the manufacturer’s instructions.
Composite application
- Insert the material from the syringe or coil into the cavity and model.
- Maximum layer thickness 2 mm.
Curing
- Expose each layer for 20 seconds using a dental polymerization unit.
- Hold the light guide as close as possible to the surface.
Finishing and polishing
- After polymerization, finish directly with finishing diamonds, silicone polishers or polishing brushes.
- Check occlusion and articulation.
Special notes
- Do not place the operating light too close to the material to avoid premature curing.
- Carry out polymerization with a device in the 350 – 500 nm spectrum.
Vickers Hardness | 948 MPa |
---|---|
Bending strength | 157 MPa |
E-module | 16575 MPa |
Compressive strength | 432 MPa |
Diametral tensile strength | 56 MPa |
Radiopacity | 220% |
Vol. shrinkage | 1,66% |
